SKF FY 35 FM Square flanged ball bearing unit with eccentric locking, cast iron housing

SKF FY 35 FM
Square flanged ball bearing unit with eccentric locking, cast iron housing, ISO
These square flanged ball bearing units are compliant with ISO standards. They consist of an insert bearing, with a narrow inner ring and eccentric locking, and are intended primarily for use in applications where the direction of rotation is constant. The bearing is mounted in a cast iron housing, which can be bolted to a machine wall or frame. Ball bearing units can accommodate moderate initial misalignment, but normally do not permit axial displacement.
Resist high levels of contamination
Designed for high temperatures and speeds
Accommodate relatively heavy loads
Cost-effective

Dimensions
Shaft diameter                                             35 mm
Housing overall width                                 34.5 mm
Width, total                                                 50.4 mm
Centre distance between bolt holes           92 mm
Bearing width, total                                    38.9 mm

Performance
Basic dynamic load rating                          25.5 kN
Basic static load rating                               15.3 kN
Limiting speed                                           5 300 r/min
Note                                                     Limiting speed with shaft tolerance h6

Product net weight                                    1.33 kg
eClass code                                                23-05-08-02
UNSPSC code                                             31171536
